UVFPC Flat Polycarbonate Sheet
A Leading supplier of Flat solid polycarbonate sheets and coating service
With more than 15 years of experience, UVPLASTIC has been a leading manufacturer of Flat Polycarbonate Sheets in China, the annual production is more than 9,000 tons.
UVFPC is a family code of Flat Polycarbonate Sheets, which is available in a wide range of colors, surface types, and different clarity from clear, translucent to opaque. UVFPC offers a wide range of thicknesses from 1mm to 20mm, Max. width is 2.65m and flexible Lengths. Meantime, it includes diffusion sheets, flame retardant polycarbonate sheets, and coating polycarbonate sheets, such as anti-static, anti-fog, and abrasion resistant polycarbonate sheets.
Today, UVFPC Flat Polycarbonate Sheets have been used in a wide range of industries including construction & architecture, transportation, safety & security, PPE, medical industry, Sign & Display, sports equipment, luminaire, tourism & entertainment, industrial fabrication, etc.
Main Benefits
- 250 times stronger than glass, but half weight, virtually unbreakable, the right material of riot shield and safety glazing or vandalism protection;
- Glass-like and up to 92% light transmission;
- With wide options in colores and surface types, easy to make an eye-catching appearance;
- Co-extruded UV protective layers on one or two sides for improved durability;
- ESD coating layer is for anti-static polycarbonate sheet;
- Great anti-fog coating technology, always optically clear even under high humidity condition;
- Excellent flame retardation, meeting V0/U94;
- Easy to fabricate, flexible, formable and machinable, cold/hot bend, thermoform to shapes;
- The right material for the LED light diffuser and can be thermoformed and coated with the ESD layer;
- Wonderful ink adhesion and print quality;
- Withstands most extreme hot and cold climates between -40°C to 120 °C;
- With hard coating, the pencil hardness of the surface is up to 7H;
- The thickness is up to 20mm, width is up to 2.65m;
- Integrated polycarbonate fabrication service is available;
You Need to Tell Us
For a fast quotation, you need to tell us the following information
Thickness
Thickness is the main factor for cost, you can choose the right one between the standard thickness from 0.8mm to 20 mm, Max. thickness is up to 50 mm;
Size
UVPALSTIC provides polycarbonate sheets with standard and custom sizes, the Max. Width is 2.65 m, the length can be customized.
Coating Requirement
We provide the high-quality coating layer, including anti-fog coating, anti-static coating, nonglare coating, abrasion-resistant coating.
Quantity
More quantity results in the low production cost, therefore, clients need to tell us the Max. quantity, it will help you get the most competitive price.
Application
Tell us your application, we need to confirm the model you choose is right, meantime, our engineers can give more suggestions under your budget.
Product Specification
| No. | Product Name | Model | Thickness Range (mm) | Standard Width (mm) |
|---|---|---|---|---|
| 1 | Solid Polycarbonate Sheet | UVFPC-SO | From 0.8mm to 20mm | 1220mm, 2100mm, 2650mm |
| 2 | Anti-fog Polycarbonate Sheet | UVFPC-AG | From 0.8mm to 14mm | 930mm, 1220mm |
| 3 | Flame Retardant Polycarbonate Sheet | UVFPC-FL | From 0.8mm to 20mm | 1220mm, 2100mm, 2650mm |
| 4 | Anti-static Polycarbonate Sheet | UVFPC-ESD | From 0.8mm to 12mm | 930mm, 1220mm |
| 5 | Abrasion-Resistant Polycarbonate Sheet | UVFPC-HC | From 0.8mm to 14mm | 930mm, 1220mm |
| 6 | Frosted Polycarbonate Sheet | UVFPC-FR | From 1.5mm to 15mm | 1220mm, 2100mm |
| 7 | Embossed Polycarbonate Sheet | UVFPC-EM | From 3mm to 15mm | 1220mm, 2100mm |
| 8 | Polycarbonate Diffuser Sheet | UVFPC-DI | From 0.8mm to 12mm | 1220mm, 2100mm |
Remark:
Custom colors are available;
Polycarbonate fabrication services are available;
Contact us for polycarbonate sheets with over 20 mm thick;
Click HERE for more detail about thin polycarbonate sheet (thickness is between 0.125mm to 1.5mm), called as polycarbonate film;
| Type | Color Description | Surface |
|---|---|---|
| Transparent | Clear, Bronze, Red, Blue, Green, Solar Grey, LighterBlue, Lighter Green | Smooth, Frosted, Embossed |
| Translucent | White Opal, White Diffuser, Yellow, Red, Mint Green, White Opal | Smooth, Frosted, Embossed |
| Opaque | Black, Yellow, Dark Blue, Cream, Dark Grey, Dark Brown | Smooth, Frosted, Embossed |
Remark:
UVPLASTIC can provide custom colors upon clients’ request, subject to a minimum order.
| Property | Test Method | Testing Condition | Unit | Value |
|---|---|---|---|---|
| Density | D-792 | g/cm3 | 1.2 | |
| Heat Deflection Temperature | D-648 | Load: 1.82 MP | °C | 135 |
| Short Term Service Temperature | °C | from -50 to +130 | ||
| Long Term Service Temperature | °C | from -40 to +100 | ||
| Coefficient of Linear Thermal Expansion | D-696 | mm/m °C | 0.065 | |
| Thermal Conductivity | C-177 | W/m K | 0.21 | |
| Tensile Strength at Yield | D-638 | 10 mm/min | Mpa or N/mm² | >65 |
| Tensile Strength at Break | D-638 | 10 mm/min | MPa or N/mm² | >60 |
| Elongation at Yield | D-638 | 10 mm/min. | % | 6 |
| Elongation at Break | D-638 | % | >95 | |
| Tensile Modulus of Elasticity | D-638 | 1 mm/min | MPa | 2350 |
| Flexural Strength | D-790 | 1.3 mm/min. | MPa | 100 |
| Flexural Modulus | D-790 | 1.3 mm/min. | MPa | 2600 |
| Impact Falling Weight | ISO 6603/1 E50 | 3mm sheet | J | 158 |
| Light Transmission | D-1003 | % | 82 – 92 | |
| Haze | D-1003 | % | <0.5 | |
| Flammability rate | UL 94 | V-2 or V-0 |
Remark:
Default third-party testing organization is SGS;
Applications
UVPLASTIC Solid Polycarbonate sheet is an ideal material for external applications such as roofing panels, building facade systems. It is lightweight, high impact resistant, and offers wonderful weatherability. A wide variety of colors and sizes are available. It is easy to bend and drill polycarbonate sheet;
Polycarbonate is stronger than PMMA, PETG and other plastics, meantime, it offers excellent ink adhesion for applications. UVPLASTIC has fabricated many sign and logos for car companies, fast-food companies, and cosmetics companies.
UVPLASTIC solid polycarbonate sheet is the best material for home DIY projects like polycarbonate carport, swinming poor encluser, pergola, etc.
Frequently Asked Question
Polycarbonate cost is different according to thicknesses, sizes, colors, raw material, and manufacturers. Normally, polycarbonate prices in America and Europe are higher than in China, but the quality is same. UVPLASTIC stock the common solid polycarbonate sheets, the following price list is for your reference:
| Model | Brand | Description | Unit Price | Situation |
|---|---|---|---|---|
| UVFPC-SO-1.5 | UVPLASTIC | .060” (1.5mm), clear, 8×4 ft; | $13-$20/sheet | in stock |
| UVFPC-SO-2 | UVPLASTIC | .078” (2mm), clear, 8×4 ft; | $17-$25/sheet | in stock |
| UVFPC-SO-3 | UVPLASTIC | .118” (3mm), clear, 8×4 ft; | $27-$35/sheet | in stock |
| UVFPC-SO-4 | UVPLASTIC | .157” (4mm), clear, 8×4 ft; | $37-$45/sheet | in stock |
| UVFPC-SO-5 | UVPLASTIC | .196” (5mm), clear, 8×4 ft; | $47-$55/sheet | in stock |
| UVFPC-SO-6 | UVPLASTIC | .236” (6mm), clear, 8×4 ft; | $57-$65/sheet | in stock |
| UVFPC-SO-8 | UVPLASTIC | .315” (8mm), clear, 8×4 ft; | $77-$85/sheet | in stock |
| UVFPC-SO-10 | UVPLASTIC | .393” (10mm), clear, 8×4 ft; | $97-$110/sheet | in stock |
| UVFPC-SO-12 | UVPLASTIC | .472” (12mm), clear, 8×4 ft; | $117-$125/sheet | in stock |
| UVFPC-SO-14 | UVPLASTIC | .551” (14mm), clear, 8×4 ft; | $137-$145/sheet | in stock |
| UVFPC-SO-15 | UVPLASTIC | .590” (15mm), clear, 8×4 ft; | $147-$160/sheet | in stock |
Remark:
- Contact us for the accurate price;
- Custom thicknesses are available;
- Max. Thickness is 20mm;
- Max. Width is 2650mm;
- Polycarbonate coating is available;
- Polycarbonate fabrication is available;
Flat polycarbonate sheets are used for a wide variety of industries, different testing reports and certificates will be needed for projects in North America and Europe.
Maybe, UVPLASTIC doesn’t have the testing report/certificate, it doesn’t mean that our products can’t pass the testing. We accept any third testing organization that the client appoints, or SGS will be the default third testing organization, they will test our products before shipping.
Polycarbonate is 250 times stronger than glass, 20 times stronger than the acrylic sheet. Therefore, polycarbonate sheet is the ideal material for safety glazing like police riot shield, skylight dome, roofing, and bullet-proof glass, motorcycle shield, clear kayak, etc.
The extruded UV protective layer will be needed, if the polycarbonate sheet is used outdoor, or it will turn yellow. But different manufacturers will offer UV protective layers with different thicknesses and different concentrations, therefore, the unqualified polycarbonate sheet will turn yellow in a short time. As a leading manufacturer and ONE-STOP supplier of polycarbonate and acrylic sheets, UVPLASTIC puts quality as the first consideration. UVFPC-SO-U1/U1A/U2 offer 10 years of warranty. Contact our engineer, if you need a longer warranty or any special requirement.
Solid polycarbonate sheet is one of plastic sheets, which offers the half weight of glass, but 250 times stronger. Meantime, solid polycarbonate sheet offers extraordinary durability and great formability, it is an ideal alternative to glass.
The original color of solid polycarbonate sheet is clear, the light transmittance is from 80% to 92% according to different thicknesses. But UVPLASTIC provides clients with a variety of colors, like grey, brown, bronze, blue, green, white, etc.
The main applications are police riot shield, suitcase, building roof, skylight dome, building facade, medical face shield, automotive industry, etc.
It depends, we offer four types of polycarbonate sheets with the different UV coating layers. Otherwise, UVPLASTIC offers more UV protective layer for 15 years of warranty.
| Model | Description |
|---|---|
| UVFPC-SO | A small quantity of UV is inside, it is for general purpose. |
| UVFPC-SO-U1 | 50 micron co-extruded UV protective layer on one side for outdoor application |
| UVFPC-SO-U1A | 50 micron co-extruded UV protective layer on the outside, anti-condensation treatment on the inside, it is for agricultural application |
| UVFPC-SO-U2 | 50 micron co-extruded UV protective layers are on both sides for outdoor application |
Polycarbonate sheets will soften if heated above 130°C, therefore, it is easy to thermoform to a certain shape. Sometimes, the heat is built-up by the high friction, you can use water or air to cool it.
We will use the wooden tray on the bottom of flat polycarbonate sheets, it is easy to carry by a forklift, please see the following images,
No. Colored polycarbonate sheet is co-extruded by the melt colored resin and clear resin, therefore, color polycarbonate sheet doesn’t discolor, and the UV coating layer is needed, if it is used outdoor or turn yellow.
UVPLASTIC can provide polycarbonate sheets with standard sizes, which can be found at product specifications. Otherwise, we can cut to size upon your requirement, the following table is the size capability,
| Item | Description |
|---|---|
| Max. Thickness | .787″ (20mm) |
| Max. Width | 8.69ft (2650mm) |
| Max. Length | 39ft (11800mm) |
Of couse, the prices are same between clear and colored polycarbonate sheet.
Maybe some companies or distributors tell you that colored polycarbonate is more expensive than clear one. It is totally wrong, they hope you pay more to them. Otherwise, in all probability, their products made of the recycled raw materials.
Any way, you need to be careful!
Yes, you can warp the polycarbonate sheets, but it should subject to the min warp radius, which is 150 or 200 times more than their thickness.
Sometimes, UVPLASTIC warps the polycarbonate sheets as roll when delivering it, it offers more length for global clients, please see the following table:
| No | Product Name | Thickness (mm) | Length With One Roll |
|---|---|---|---|
| 1 | Flat Solid Polycarbonate Sheet | 0.8 | 50 |
| 2 | Flat Solid Polycarbonate Sheet | 1 | 50 |
| 3 | Flat Solid Polycarbonate Sheet | 1.5 | 30 |
| 4 | Flat Solid Polycarbonate Sheet | 2 | 30 |
| 4 | Flat Solid Polycarbonate Sheet | 2.5 | 30 |
| 4 | Flat Solid Polycarbonate Sheet | 3 | 20 |
No, polycarbonate sheets will be damaged by some household solvents, such as Lysol, Pinesol, and Isopropanol alcohol. Using water and new cloth is the better way to lean polycarbonate sheets.
Yes, UVPLASTIC Polycarbonate Sheets can be thermoformed to shape by the standard equipment, the popular thermoforming processes are vacuum forming, free-blown forming, and line bending.
UVPLASTIC is not only a ONE-STOP supplier of polycarbonate sheets but also the provider of integrated polycarbonate fabrication service.
